PIO-821H 45ks/s High Gain 12-bit, 16 Channel Input, 1-channel D/A, Digital I/O Board

Thương hiệu: ICP DAS | Tình trạng: Còn hàng

Liên hệ

45ks/s High Gain 12-bit, 16 Channel Input, 1-channel D/A, Digital I/O Board

THÔNG TIN SẢN PHẨM

PIO-821H 45ks/s High Gain 12-bit, 16 Channel Input, 1-channel D/A, Digital I/O Board

Features

The PCI-821L/H is a high performance, multifunction board for PC/AT compatible computers. The PCI-821L provides low gain (1, 2, 4, 8) and PCI-821H supports high gain (1, 10, 100, 1000). The PCI-821L/H contains 12-bit ADC with up to 16 single-ended or 8 differential analog input channels. It also has a 12-bit DAC voltage outputs and 16 channels of TTL-compatible digital input and digital output, respectively. The maximum sampling rate of A/D converter is about 45K.sample/sec.

Maximum sample rate of A/D converter: 45K samples/sec
Software selectable input ranges
PC AT compatible PIO bus
A/D trigger mode:
- software trigger
- pacer trigger
Input Channels:
- 16 single-ended
- 8 differential analog
Programmable high gain: 1,10,100,1000 (PIO-821H)
Input range: ±5V, ±0.5V, ±0.05V, ±0.005V(PIO-821H)
Programmable low gain: 1, 2, 4, 8 (PIO-821L)
Input range: ±5V, ±2.5V, ±1.25V, ±0.625V (PIO-821L)
1 channel 12-bit D/A voltage output
16 digital input /16 digital output (TTL compatible)
Interrupt handling
PIO-821L/H card can be calibrated by software tool
